Pad-Mount Primary Metering Cabinet
Configured to Specification. Delivered in Four Weeks.
TESCO Pad-Mount Primary Metering Cabinets are engineered for utility primary metering applications requiring rugged enclosure performance and flexible CT/VT integration.
Designed to compete on durability and field usability, these cabinets combine IEEE-rated enclosure integrity with installer-focused features that reduce installation time and improve serviceability.
General Ratings & Classification
- 15 kV (95 kV BIL)
- 25 kV (125 kV BIL)
- 35 kV (150 kV BIL)
- 200A Load Break
- 600A Dead Break / Bolted
- 3-Phase, 4-Wire Grounded Wye (Delta optional)
Description
Enclosure Performance & Construction
IEEE C57.12.28 Compliant
Designed for enclosure integrity including tamper resistance and coating performance.
Material Options
- 11 or 12-gauge Galvanneal Steel (standard)
- 5052-H32 Aluminum (coastal/premium)
- 304 or 316 Stainless Steel (harsh environments)
Finish
- Standard Pad-Mount Green
- ANSI 70 Gray
Footprint
- Approx. 79″ W x 54″ H x 54″ D
(Aligned with common industry pad-mount footprints) - Low-profile option available for space-constrained sites
Installer-Centric Access & Safety
- Flip-top roof with stainless steel hold-opens for simplified CT installation
- 3-point latching door system
- Penta-head security bolts with padlock provisions
- GPO-3 fiberglass phase isolation barriers
- Clear polycarbonate barriers for visual inspection (live-front units)
Internal Integration Designed to Work as a System
Transformer Mounting
- Universal mounting rails
- Compatible with ABB, GE, Ritz, Arteche CTs/VTs
- Supports IEEE C12.11 form factors
Secondary Integration
- Factory pre-wired to TESCO Test Switches
- Integrated TESCO Meter Socket options (Form 9S / 5S)
- #10 AWG secondary wiring
- Utility-specific color coding available
Bushing Configuration
- Dead-front: 600A integral bushings or 200A bushing wells
- Live-front: Porcelain or cycloaliphatic insulators
- NEMA 2-hole or 4-hole spade terminals
Built for Utility Primary Metering Applications
- Utility primary metering
- Substation distribution points
- Solar and BESS interconnections
- Industrial and campus distribution systems
Representative engineering drawings shown for illustration. Final designs are configured per customer requirements.
Request a Quote
Provide your voltage class, current rating, and transformer manufacturer (if known), and our engineering team will configure the appropriate cabinet for your application.
Contact Us and Request a Quote today!
