L+G AXE 2S NET Electric Meter
$99.00
The Landis+Gyr (L+G) FOCUS AXe 2S NET is a specialized version of the AXe residential smart meter, specifically configured for net metering applications such as homes with solar or wind power systems.
Technical Specifications
- Form Factor (2S): Standard single-phase 3-wire residential socket mount.
- Voltage (240V): Rated for standard North American residential service.
- Class (CL200): Rated for continuous current up to 200 Amps.
- Accuracy: Exceeds ANSI requirements with a high accuracy class of 0.2% for active energy.
Description
Key “NET” Metering Features
- Bi-Directional Measurement: Specifically programmed to track power flow in two directions: Delivered (grid to home) and Received (home to grid).
- Net kWh Calculation: The meter display typically cycles through multiple values, including:
- DEL (Delivered): Total electricity used from the utility.
- REC (Received): Total excess electricity sent back to the grid.
- NET: The calculated difference (Delivered minus Received), which can go up or down based on production.
- Display Options: Features a high-resolution 9-digit LCD that can be programmed to show specific net metering metrics.
Advanced AXe Platform Features:
- Enhanced Processing: Utilizes a third-generation processor that is twice as fast as the previous FOCUS AX model, with 4x more non-volatile memory for better data profiling.
- Power Quality Metrics: Capable of logging voltage sags, swells, and Total Harmonic Distortion (THD).
- Tamper Protection: Includes a sensor to detect meter removal and insertion.
- Communication: Supports Gridstream RF Mesh and cellular (LTE-M) modules for remote data transmission to the utility.
Usage and Applications
This meter is the standard choice for utilities managing residential customers with renewable energy generation. It allows for accurate billing by reporting the “net” energy consumed after accounting for the energy the customer produced.
