Meter Engineering Board (MEB)
Key Features:
- Perform baseline meter accuracy testing
- Run demand and time-run tests
- Conduct comparative accuracy tests across varying load conditions
- Includes PC-based software for Ethernet-connected operation
- Automated voltage routing for supported meter forms:
1S-6S, 8S-17S, 25S, 26S, 29S, 32S, 35S, 36S, 45S, 56S, 66S, 76S, 103S, 106S, 109S, 112S, 116S, 125S, 135S, 136S, 145S, 166S - Electronically actuated socket controls
- Integrated user interface with display and keypad
- Load-side power indication lamps
- Internal potential routing relays
Description
Qualification, Disconnect, Communication & Functional Testing with Integrated 0.1% Accuracy
TESCO’s Meter Engineering Board (MEB/MEB3) is designed to perform qualification, disconnect, communication, and advanced functional testing. With built-in basic metrology (0.1% accuracy), the MEB supports utilities and meter manufacturers in a range of meter evaluation and verification tasks.
The MEB can be used as a qualification platform, a time-run or demand board, or as part of a meter certification program. Its electronically controlled socket design supports automated operation to streamline meter testing. The system offers a flexible and efficient way to perform both basic and advanced test routines in a controlled environment.
Supported Applications:
- Meter qualification and certification
- Disconnect switch testing
- Communication performance testing
- Power Line Communication (PLC) testing
- Software and firmware verification
- Meter configuration and setting verification
- Functional, demand, and time-run testing
- Extended use and lifecycle testing
