Precision Multirange Voltage Transformers (WP-36000)
The WP-36000 Transformer is primarily a laboratory standard.
The primary ranges for the WP-36000 vary by model. The models are differentiated by the two intermediate ranges:
- Model WP-36000-1: 14,400, 18,000, 20,760, and 36,000 volts. Secondary: 120 volts.
- Model WP-36000-2: 14,400, 16,800, 24,000, and 36,000 volts. Secondary: 120 volts.
- Model WP-36000-3: 14,400, 21,000, 24,000, and 36,000 volts. Secondary: 120 volts.
Description
The high degree of accuracy and multiplicity of ranges makes this transformer the standard for precision calibration work. With the aid of this transformer, very accurate determination can be made of the ratio and phase angle characteristics of voltage transformers having ratings from 14,400 to 36,000 volts.
Additionally, the range of a voltmeter or wattmeter can be accurately extended by this transformer to cover all voltage values from 14,000 to 36,000 volts.
Other intermediate ranges are available. Consult Knopp for more information.
The WP-36000 Transformer, like other Knopp Precision Multirange Transformers, has excellent ratio and phase angle characteristics with respect to both inter-range accuracy and overall accuracy. This is made possible through a properly engineered design and through exclusive, highly perfected compensating and winding methods.
The WP-36000 does not provide the Knopp One-to-One Calibrating Feature, however, for those who have a WP-14000 Knopp Precision Multirange Voltage Transformer Standard with the Knopp One-to-One feature, the benefit of the One-to-One calibration can be extended to the WP-36000 by comparing the 14400-volt ranges of the two transformers, using the WP-14000 as the standard.
