L+G AXe 1S Electric Meter
$89.00
The Landis+Gyr (L+G) FOCUS AXe 1S is a solid-state residential smart meter designed for lower-voltage, 2-wire applications, often found in older residences or specific light commercial setups.
Technical Specifications:
- Form Factor (1S): Single-phase, 2-wire self-contained socket mount.
- Voltage (120V): Specifically designed for 120V services (unlike the 240V 2S model).
- Class (CL100): Typically rated for a maximum continuous current of 100 Amps.
- Accuracy: Exceeds ANSI requirements with a typical accuracy of 0.2% for active energy.
- Starting Load: Highly sensitive, beginning measurement at approximately 3.6 watts (0.030 Amps).
Description
Key Features:
- Advanced AXe Platform: Features the third-generation processor and expanded memory (RAM/ROM) found in the AXe series, enabling advanced power quality and data profiling.
- Power Quality Metrics: Capable of logging voltage sags and swells, and monitoring Total Harmonic Distortion (THD).
- Remote Disconnect (Optional): Available in the AXe-SD configuration, which includes an integrated 200A motor-driven cam-action switch for remote service management.
- Data Profiling: Supports up to 8 standard channels of Load Profile data for granular usage tracking.
- Tamper Detection: Equipped with sensors to detect meter removal and insertion, as well as magnetic or DC presence detection.
- Display: Features a high-resolution 9-digit LCD with programmable scroll sequences.
Usage and Applications
- Single-Phase 120V Service: Used primarily for older residential properties or small apartments that utilize a single 120V “hot” wire and a neutral.
- AMI Integration: Fully compatible with Landis+Gyr’s Gridstream RF mesh or cellular communication modules for over-the-air firmware updates and remote billing.
- Net Metering: Like the 2S model, it can be configured for bi-directional measurement for small-scale 120V renewable energy installations.
