Catalog No. 202 - A-Base Jumpers
TESCO A-Base Catalog No. 202
TESCO A-Base Catalog No. 202
TESCO A-Base Jumpers (Cat. 202) allow meter technicians to jump either customer-load or test-load on A-Base meter installations. TESCO A-Base Jumpers are equipped with alligator-clip connectors, and are available in either 10 gauge wire, which is rated for 30 amps or 8 gauge wire, which is rated for 75 amps.
TESCO also offers Potential Jumpers, which are equipped with crocodile-clip connectors, and are available in 18 gauge wire and rated for 5 amps/600 volts.
TESCO jumpers are built with the tradition of reliability and ruggedness. For more information, contact your local sales representative.
Equipment Documentation
Specifications
Catalog No. 202
10 Gauge, Rated at 30 Amps.
Catalog No. 202-8AWG
8 Gauge, Rated at 75 Amps.
Catalog No. 202-4AWG
4 Gauge, Rated at 100 Amps.
Cable Length
24" Standard (custom lengths available)
Catalog No. 203
18 Gauge, Rated at 5 Amps; 600 Volts
Cable Length
24" Standard (custom lengths available)
